New for 2023
Standard Colors
Standard Features
On-Demand 2WD
Universal Spare Wheel (Fits All 3 Positions)
Spare Wheel Luggage Rack
LED Sidecar Fog Lights
Front Sidecar Bumper
Sidecar Auxiliary Power Outlet
Sidecar Tonneau Cover
Sidecar and Trunk Floor Protection
Jerry Can
Folding Utility Shovel
Ural Tool Kit
Touch Up Paint
*Right-hand 2023 Model shown here. Left-handed photos coming soon!
Tech Specs
Engine and Transmission
Displacement, cc: 745
Engine type: OHV air cooled 2 cylinder 4 stroke “boxer” (flat twin)
Valve per cylinder: 2
Bore and stroke (mm x mm): 78 x 78
Max output: 30kW @ 5500 rpm
Max torque: 54 Nm @ 4300 rpm
Compression: 10.5:1
Fuel system: Throttle body EFI
Starting: Electric & Kickstart
Clutch Double-disc dry
Transmission type: Manual
Speeds: 4 forward 1 reverse
Primary drive (rear wheel): Driveshaft
Final drive ratio: 4.62
Engageable sidecar wheel drive: Yes, driveshaft
Physical Measurements
Overall length, mm: 2580
Overall width, mm: 1700
Overall height, mm: 1100
Seat height, (unladen), mm: 790
Mass in running order, kg: 363
Chassis
Front suspension: IMZ leading link fork
Rear suspension: Double sided swing-arm with two Sachs hydraulic spring shock absorbers, 7x adjustable
Sidecar suspension: Single sided swing-arm with Sachs hydraulic spring shock absorber, 7x adjustable
Wheels: 2.15X19 Aluminum rims with steel spokes
Tyres: Heindenau K37, 4.0×19′′
Front brake: 4-piston fixed Brembo caliper with 295mm floating NG rotor
Rear brake: Two-piston fixed Brembo caliper with a 265mm floating NG
rotor with a standalone mechanical parking brake caliper by J.JuanSidecar brake: 2-piston fixed Brembo caliper with 245mm floating NG rotor
Misc.
Fuel grade: 95 Octane
Fuel tank capacity, l: 19
Reserve, l: app. 3,8
Estimated fuel economy: 4,4l / 100 km
Estimated range, km: 430
Max permissible weight, kg: 635
Trunk volume, l: 82
Warranty
2 year unlimited kilometre, parts and labour
